UTP KABL CAT5E 305M DAHUA 4X2XAWG24 OUTDOOR CABLE DH-PFM920-5EU

MODEL : DH-PFM920-5EU305M OUTDOOR UTP CAT5E CABLE. 305.0 M (1000 FT)/CARTON OUTDOOR UTP CAT5E, POWER OVER ETHERNET, COMPATIBLE WITH ONE CABLE. HIGH-PURITY OXYGEN-FREE COPPER CONDUCTOR MATERIAL. CUSTOMIZED MDPE OUTER SHEATH MEET ANSI/TIA 568-C.2 FLAME RETARDANT CLASS CERTIFIED. ENVIRONMENTALLY FRIENDLY AND ALL MATERIALS USED ARE ROHS COMPLIANT.SPECIFICATION : MATERIAL OXYGEN FREE COPPER (99.97% PURITY), DIAMETER 0.50 MM ± 0.01 MM(0.02″± 0.0004″), AMERICAN WIRE GAUGE 24AWG, MATERIAL HDPE, MIN. AVERAGE THICKNESS 0.21 MM(0.0082″), DIAMETER 0.89 MM ± 0.06 MM(0.04″± 0.0023″), COLOR 8-CORE, BLUE, WHITE/BLUE ORANGE, WHITE/ORANGE GREEN, WHITE/GREEN BROWN, WHITE/BROWN, MATERIAL POLYESTER, SPECIFICATION 500D, WRAP MATERIAL POLYESTER TAPE (TRANSPARENT), DIMENSION W: 20MM±2MM*T: 0.026MM±0.02MM(W: 0.78″±0.07″*T: 0.0010″±0.0007″), SHEATH MATERIAL MDPE, MIN. AVERAGE THICKNESS 0.7 MM(0.03″), DIAMETER 5.2 MM ± 0.4 MM(0.20″± 0.0157″), COLOR BLACK, ELECTRICAL MAX. DC RESISTANCE OF A SINGLE CONDUCTOR 9.5?/100 M, MIN. INSULATION RESISTANCE 5000M OM·KM, MAX. DC RESISTANCE UNBALANCE 2% (PAIR INTRA), 4% (PAIRS INTER), DIELECTRIC STRENGTH NO BREAKDOWN WITH 1KV DC FOR 1 MIN, TRANSMISSION CHARACTERISTIC IMPEDANCE 100 ± 15?, NEAR END CROSS TALK ?35.30 DB/100 M@100 MHZ, MAX. ATTENUATION 22 DB/100 M@100 MHZ, RETURN LOSS ?20.1 DB/100 M@100 MHZ, OPERATION TEMPERATURE –30°C TO +60°C (–22°F TO 140°F), INSTALLATION TEMPERATURE –5°C TO +50°C (23°F TO 122°F), STORAGE TEMPERATURE AND HUMIDITY –10°C TO +40°C (14°F TO 104°F), <60% (RH), PACKAGING LENGTH 305M (1000.66 FT) ± 1.5 M (4.92 FT). EXECUTIVE STANDARD ANSI/TIA 568-C.2
